Diverge 4 Alloy
The Ultimate Getaway Vehicle
Race-tuned. Adventure-approved. The Diverge 4 gravel bike in E5 Alloy is built for full-gas race days and off-grid epics. With Future Shock 3.0, our most responsive frame ever, massive tire clearance, and internal storage for the first time ever on an alloy bike, the best gravel bike in the world just got better. Chase the horizon—or your rivals—it’s built for both.
Frameset
Frame
Specialized Diverge E5 Premium Aluminum, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc, UDH dropout
Suspension
Fork
Future Shock 3.1 w/ Smooth Boot, FACT Carbon 12x100mm, thru-axle, flat-mount disc
Brakes
Front Brake
Shimano CUES Hydraulic Brake
Rear Brake
Shimano CUES Hydraulic Brake
Drivetrain
Shift Levers
Shimano CUES ST-U6030
Rear Derailleur
Shimano CUES 11-speed w/ Shadow Plus
Cassette
Shimano, CS-LG400-11, CUES, 11-Speed, 11-50t
Crankset
Shimano CUES FC-U6040, 40t
Bottom Bracket
Shimano Threaded BSA BB
Wheels & Tires
Front Tire
Tracer 700x45, Tubeless Ready
Front Wheel
AXIS Elite Disc
Rear Tire
Tracer 700x45, Tubeless Ready
Rear Wheel
AXIS Elite Disc
Inner Tubes
Presta, 700x32-50mm
Cockpit
Handlebars
Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
Saddle
Body Geometry Power Sport, steel rails
SeatPost
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Seat Binder
Alloy, 30.8mm
Accessories
SWAT
SWAT 3.0 internal downtube storage
Weight
Weight
10.74 kg (23 lb, 10.8 oz)
Weight Size
56
| Crank Length |
170 |
170 |
172.5 |
172.5 |
175 |
175 |
| Handlebar Width |
380 |
400 |
420 |
420 |
440 |
440 |
| Stem Length |
60 |
70 |
80 |
90 |
100 |
100 |
| Saddle Width |
155 |
155 |
143 |
143 |
143 |
143 |
| Seatpost Length |
350 |
350 |
400 |
400 |
400 |
400 |
| Stack |
563 |
578 |
592 |
610 |
634 |
659 |
| Reach |
365 |
374 |
387 |
400 |
412 |
425 |
| Head Tube Length |
90 |
104 |
116 |
135 |
161 |
187 |
| Head Tube Angle |
70 |
70.5 |
71 |
71 |
71 |
71 |
| BB Drop |
85 |
85 |
85 |
85 |
85 |
85 |
| Trail |
72 |
68 |
65 |
65 |
65 |
65 |
| Fork Length, Full |
391 |
391 |
391 |
391 |
391 |
391 |
| Fork Rake/Offset |
55 |
55 |
55 |
55 |
55 |
55 |
| Front Center |
604 |
613 |
626 |
645 |
665 |
686 |
| Chainstay Length |
430 |
430 |
430 |
430 |
430 |
430 |
| Wheelbase |
1019 |
1031 |
1041 |
1060 |
1081 |
1102 |
| Top Tube Length, Horizontal |
521 |
537 |
556 |
575 |
593 |
613 |
| Bike Standover Height |
700 |
725 |
754 |
779 |
805 |
832 |
| Seat Tube Length |
400 |
430 |
470 |
500 |
530 |
560 |
| Seat Tube Angle |
74.5 |
74 |
74 |
74 |
74 |
74 |
